Series 10

  • Excellent Polymer Activation
  • Accurate, Repeatable, Polymer Dosing
  • Robust Construction
  • Easy Installation
  • Few Moving Parts



General Information

Downloads

Download a fully detailed brochure with more information.

Aditional Information



ActiFlex Series 10 “Low Volume Direct to Process”

MODEL

S10.10

S10.20

S10.40

Dilution Water

10 L/min

2.5 gpm

20 L/min

5 gpm

40 L/min

10 gpm

Neat Polymer Flow 1.0%



100 ml/min

38 gal/day

200 ml/min

76 gal/day

400 ml/min

152 gal/day

Secondary Dilution

N/A

N/A

N/A

Inlet Water Pressure

40-60 psi

40-60 psi

40-60 psi

Feed Pump Type – Std.





Mechanical Diaphragm



Optional PC Pump



Mechanical Diaphragm



Optional PC Pump



Mechanical Diaphragm



Optional PC Pump



Tank Level Control

Optional

Optional

Optional

Construction

PVC Piping – Standard

SS  -Optional

PVC Piping – Standard

SS  -Optional

PVC Piping – Standard

SS  -Optional

Voltage

110/220 vac

110/220 vac

110/220 vac
